10.0 Specifications
Specifications
General
Input Impedance 10kOhm balanced or unbalanced
Input Headroom >+20dBu
Max Output level >+21dBu into 600 ohms or greater
Output Impedance <50 Ohms unbalanced or unbalanced
Frequency Response <5Hz to >45kHz +/-1dB
Noise <-94dBu 22Hz to 22kHz
Dynamic Range > 115dB
Cross Talk <-80dB @1kHz
Distortion <0.005%THD (80kHz measurement BW) 20Hz-20kHz, 0dBu
GAIN control +10dB to -infinity
HP filter control OUT to 250Hz @ 12dB/octave
LF contour +/-6dB shelving @ 50Hz 6dB/octave
HF contour +/-6dB shelving @ 14kHz 6dB/octave
FREQUENCY bands +/-15dB on ISO centres with a Q of 4
HP filter set to OUT. Gain, HF, LF & all sliders set to 0.
Note that the filters are removed from the signal path when the slider is in the central 'zero' position.
