BST MD48 Series User Manual

2.4 SPECIFICATIONS
Introduction
Model MD48-50-2U MD48-100-3U
General
Nominal Energy ( kWh ) 2.4 5.12
Usable Energy ( kWh ) 2.4 5.12
Scalability Max. 15 in parallel (36 kWh) Max. 15 in parallel (76.8 kWh)
Design Life
10 Years at 25℃
Mechanical
Dimension ( W x H x D, mm ) 440 x 410 x 88.5 440 x 420 x 133
Weight ( kg ) ~24 ~44kg
Loading Quantity
32 pcs / pallet 25 pcs / pallet
320 pcs / 20’GP, 704 pcs / 40’GP 250 pcs / 20’GP, 550 pcs / 40’GP
Electrical
Nominal Voltage ( V ) 48 51.2
Operating Voltage Range ( V ) 40.5 ~ 53.5 43.2 ~ 56.8
Recommend Charge/Discharge
Current ( A )
25 / 25 50 / 50
Maximum Charge/Discharge
Current ( A )
50 / 50 100 / 100
Operating
Charge Temperature (℃)
0 ~ 50
Discharge Temperature (℃)
-10 ~ 50
Storage Temperature (℃)
-20 ~ 45
Humidity 5%~95% RH ( No Condensation )
Altitude
≤ 4000m
Ingress Protection IP20
Communication Interface CAN, RS485 ( Optional WIFI, BLE)
Certification UN38.3, EN 61000-6-1, EN 61000-6-3, IEC62619
Compatible Inverters
BST/SMA/Deye/GOODWE/Growatt/Sofar/Solis/Victron/Voltronic/
Sermatec
05
*When the temperature is not in the range of 0 ~ 40℃, the performance will be limited.
