2 WIRE Switchboard
Wiring diagrams
Master SWB = 0
Main EP
(P = 1)
– An additional power supply with 346020 is recommended.
– Use the YouDiagram software for the functional check and calculation of the current absorptions –
free download from www.professionisti.bticino.it (for Italy) - www.bticino.com (International version).
– Refer to the documentation supplied with the product or the configuration software to configure the Switchboard.
WARNING
To the Internal Unit
or Riser interfaces
System with a single riser and a 2 WIRE switchboard
ITEM DESCRIPTION
346310 Switchboard
346020 Additional power supply
F441 Audio/video node
346000 Power supply
