C−LRV lift control valve Operating controls and indicators
38/92
300−I−9010212−E−10/08.08
Description of function
S By pressing any of the keys 1 to 4, the C−DELCON switches into
parameterisation mode. No travel is possible; the green RUN LED on
the C−DELCON goes out
S Select the desired parameter using the ↑ or ↓ key
S Increase value with + key, decrease value with − key
S With ↑ or ↓ key, save the value and return to parameter selection
S With keys 1, 2, 3 or 4, do not save the value and return to parameter-
isation mode
S If no key pressed within 5 minutes, the DELCON automatically quits
parameterisation mode (changes to the currently displayed parameter
are not saved)
Important: In order to quit parameterisation mode:
S either press keys ↑ and ↓ simultaneously (changes to the cur-
rently displayed parameter are saved)
or
S unplug cable and wait for about 3 seconds (changes to the cur-
rently displayed parameter are NOT saved)
C−DELCON will return to RUN mode.
