3.2 Configuration
3.2.1 Front view
STOP
START
3
4
1
2
5
6
Fig.1: Front view
1 Control elements
(See Chapter3.2.3 "Control ele-
ments", page12)
2 Oxygen analyzer
(Front cover oxygen analyzer)
3 Side connections
(See Chapter3.2.2 "Side connec-
tions", page12)
4 Ventilation slots
5 Castor brake 6 Solvent collection flask
