30
Glass Oven B-585
9.2 Error messages
Error message Possible cause Remedy
Main switch dors not Device is turned off, power supply Switch on the device, check power supply
light up voltages is missing or fuse defective voltage and fuses
No temperature Display or print defective Check power supply voltage/fuses and replace them,
indication send device to service center
Oven does not heat Nopower supply voltage or fuses Check heating leed,
defective
Motor does not turn Device is turned off, no mains voltage Switch on the instrument,
or fuses devective, motor set is on checkt the controll cable,
0 r/min, controll cable is not pluged please contact the service department
in properly,
E1 Internal temperature sensor defective Please contact service department
E2 Internal temperature sensor defective Please contact service department
E3 Internal temperature sensor defective Please contact service department
E9 Heating cefective Please contact service department
E10-11 Heating cefective Please contact service department
9 Appendix
9 Appendix
9.1 Technical data
Supply voltage 100 - 230 VAC +/-10 %
Frequency 50/60 Hz
Power max. 450 W
Pin assignment Pin 1: Ground (Gnd)
Pin 2: + 24 V DC
Pin 3 to 8: not assigned
Warm-up time ca. 10 min. (from 20°C to 300°C)
Temperature regulation range 40-300°C
Temperature accuracy +/- 5°C (in the middle of the oven at 300°C)
Drying Drying volume max. 100-250 ml
Dimensions 410 x 300 x 300 (width x depth x heigth)
Weight 9.5 kg
Kugelrohr Distillation volume max. 10-60ml
Rotational speed 0-50 rpm.
Dimensions 650 x 300 x 300 (width x depth x heigth)
Weight 11.5 kg
Ambient temperature 5-40°C
Installation category II
Pollution degree 2
Environmental conditions for indoor use only, altitude up to 2000 m.
maximum relativ humidity 80% for temperatures up to 30°C
decreasin linearly to 50% relative humidity at 40°C
