Product description2
2 Product description
The main components of the Logano GE515 oil- and
gas-fired special boiler are:
– Boiler block (Fig. 1, item 3).
The boiler block transfers the heat generated by the
burner to the heating water.
– Boiler shell (casing, Fig. 1 and Fig. 2, item 1),
thermal insulation (Fig. 1, item 2).
Boiler shell and thermal insulation prevent energy
loss.
– Control device (Fig. 1, item 4).
The control device is designed to monitor and control
all electrical components of the Logano GE515 oil-
and gas-fired special boiler.
Fig. 1 Logano GE515 oil- and gas-fired special boiler
1 Boiler shell (casing)
2 Thermal insulation
3 Boiler block
4 Control device
Fig. 2 Logano GE515 oil- and gas-fired special boiler
1 Boiler shell (casing)
2
3
4
1
1
1
1
1
