10-22 Vehicle Care
Front Wiper Blade
Replacement
To replace the front wiper blades:
1. Lift the wiper arm from the
windshield until no further
movement is possible.
2. Press the release button on the
top side of the wiper and pull the
wiper blade out of the end of the
wiper arm.
3. Install the wiper blade connector
by sliding into the end of the
wiper arm until the button on the
wiper blade clicks into place with
the wiper arm.
4. Place the wiper arm with the
wiper blade in place back on the
windshield.
Notice: Damage may occur if the
wiper blades are not in contact
with the windshield before
turning on the wiper system.
Rear Wiper Blade Replacement
The rear wiper blade and wiper arm
have a cover for protection. The
cover must be removed before the
wiper blade can be replaced.
To remove the cover:
1. Grasp the cover at the base and
pull upward to unsnap.
2. Slide the cover toward the wiper
blade tip to unhook it from the
blade assembly.
3. Remove the cover.
4. After wiper blade replacement,
ensure that the cover hook
slides into the slot in the blade
assembly.
5. Snap the cover down to secure.
