Fuses Usage
HVAC Climate Control System
FUEL/PUMP Fuel Pump
AIRBAG/
DISPLAY
Airbag, Display
COMPASS Compass
ABS Antilock Brake System
Fuses Usage
ETC/ECM
Electronic Throttle Control, Engine
Control Module
A/C CMPRSR Air Conditioning Compressor
INJ 1 Injectors 1
ECM/TCM
Engine Control Module,
Transmission Control Module
TRANS Transmission
EMISSIONS1 Emissions 1
ABS SOL Antilock Brake Solenoid
ECM IGN Engine Control Module, Ignition
INJ 2 Injectors 2
EMISSIONS2 Emissions 2
WPR Windshield Wipers
AUX PWR Auxiliary Power
WSW/RVC
Windshield Washer, Regulated
Voltage Control
LT LO BEAM Driver Side Low-Beam Headlamp
RT LO BEAM
Passenger Side Low-Beam
Headlamp
FOG LAMPS Fog Lamps
LT HI BEAM Driver Side High-Beam Headlamp
5.3L V8 Engine
5-114
