Buick Encore Owner Manual (GMNA-Localizing-U.S./Canada-15498924) -
2022 - CRC - 5/27/21
Vehicle Care 187
Mini Fuses Usage
29 Engine control module
powertrain/Ignition 1/
Ignition 2
30 EMS Var 2
31 Left high-beam headlamp
32 Right high-beam
headlamp
33 Engine control module
battery
34 Horn
35 A/C clutch
36 –
J-Case Fuses Usage
1 Electronic brake control
module pump
2 Front wiper
3 Linear power module
blower
4 IEC RC
5 –
7 –
J-Case Fuses Usage
8 Cooling fan low – mid
9 Cooling fan – high
10 –
11 Starter solenoid
U-Micro Relays Usage
2 –
4 –
HC-Micro
Relays
Usage
7 Starter
10 –
Mini Relays Usage
1 Run/Crank
3 Cooling fan – mid
5 Powertrain relay
8 Cooling fan – low
HC-Mini Relays Usage
6 Cooling fan – high
Auxiliary Fuse Block
To remove the fuse block cover, squeeze the
clips and lift it up.
Caution
Spilling liquid on any electrical
component on the vehicle may damage
it. Always keep the covers on any
electrical component.
