Bunn A10 Illustrated Parts Catalog

11
32507 071505
ELECTRICAL AND OPERATING CONTROLS
ITEM PART NO. QTY. DESCRIPTION
1 04052.0000 1 Bracket, Switch Retainer
01342.0000 2 Screw, Hex Wshr Zinc #8 x .75”
2 04069.0003 1 Thermostat Assy (Includes Items 3 and 4)
01342.0000 2 Screw, Hex Wshr Zinc #8 x .75”
3 00720.0000 1 Knob, Thermostat - Black
4 28223.0000 1 Bracket, Thermostat
02328.0003 2 Screw, PNH SLT SST #6-32 x .312”
5 21274.0000 1 Switch Assy, Start (Automatic Only)
21212.0000 1 Nut, Knurled .250-40
6 04067.0001 1 Switch, On/Off - Lighted Red (120 V)
04039.0000 1 Switch, On/Off - Lighted Red (240 V)
7 21273.0000 1 Switch Assy, Half Batch (Automatic Only)
21212.0000 1 Nut, Knurled .250-40
8 21453.0000 1 Shield, Timer Board (Automatic Only)
9 02620.1042 1 Timer, 5 min 120 V (Automatic Only)
02620.1043 1 Timer, 5 min 240 V (Automatic Only)
32400.0002 1 Timer, Digital 120 V (Automatic Only)
32400.0003 1 Timer, Digital 240 V (Automatic Only)
01342.0001 3 Screw, Hex Wshr #6-32 x .62”
01533.0003 3 Spacer, NYL - .140” ID x .250” OD
10 01711.1002 1 Cord Assy, Power 120 V (Models with large Vacation Switch)
01711.1003 1 Cord Assy, Power 120V (Models with small Vacation Switch)
01716.0000 1 Cord, Power 250 V 10 Amp
00707.0000 1 Bushing, Strain Relief (used with 120 V cord only)
11 04786.0002 1 Switch, Vacation On/Off - Black 120 & 240 V (.64” x 1.23”)
20317.0001 1 Switch, Vacation On/Off - Black 120V (.59” x .825”)
12 05749.0003 1 Plug, Black .375” dia. (Used with late model Digital Timer)
Items 13 through 18 are not Illustrated
13 21225.0000 1 Wiring Harness - Timer to Solenoid 120 V (Automatic Only)
21225.0001 1 Wiring Harness - Timer to Solenoid 240 V (Automatic Only)
14 21000.0020 1 Lead, Elec-On/Off Switch (120 V & 240 V)(Models with large Vacation Switch)
21000.0709 1 Lead, Elec-On/Off Switch (120V) (Models with small Vacation Switch)
15 28235.0001 1 Wiring Harness - TCO - Thermostat
16 21003.0139 1 Lead - Elec On/Off Switch (240 V Models only)
17 21000.0334 1 Lead - Elec On/Off Switch (240 V Models only)
18 01908.0000 1 Power Connector (Used on 240 V Models only)
01362.0000 2 Screw, OVH SLTD SST #4-40 x .50”
01509.0000 2 Lock Washer, EXT T-#4
00937.0000 2 Nut, Hex - SST #4-40
Early Models
Late Models
