7
32507 040407
TANK AND BASIN
ITEM PART NO. QTY DESCRIPTION
1 04140.0000 1 Tank Assembly 120 V (Includes Items 2-15)
04140.0008 1 Tank Assembly 240 V (Includes Items 2-15)
2 00960.0001 1 Fitting, SLTD - Tank Inlet
3 01540.0000 1 Washer, SST - .75” ID x 1.0” OD
4 01201.0000 1 Gasket, Tank Inlet
5 00942.0000 2 Nut, Hex - Brass .500-20
6 04069.0003 1 Thermostat Assembly
01342.0000 2 Screw, Hex WSHR Zinc #8 x .75”
7 05518.0000 1 Syphon Hub
8 00943.0000 2 Gasket, Tank Heater
9 04144.1000 1 Tank Heater, 1000W 120 V (Includes Item #8)
04174.1000 1 Tank Heater, 1000W 240 V (Includes Item #8)
10 04142.0001 1 Tank Lid Weldment W/Spray Tube
01380.0000 2 Screw, TRH SLTD SST #6-32
01363.0000 4 Screw, RDH WSHR SST #6-32
00973.0000 6 Nut, Keps #6-32 Zinc Pl.
01352.0000 2 Screw, Hex Wshr Zinc #8 x 1.38”
11 04844.0000 1 Gasket, Tank Lid
12 35430.0000 1 Tank, SST
13 04100.0000 1 Blanket Warmer, 40W 120 V (Models with large Vacation Switch)
33605.0000 1 Blanket Warmer, 40W 120 V (Models with small Vacation Switch)
01929.0000 1 Blanket Warmer, 34W 240 V
14 28235.0001 1 Wiring Harnes, TCO - Thermostat
15 04167.0000 1 Thermal Cut-Off W/Lead 120 V
04167.0001 1 Thermal Cut-Off W/Lead 240 V
16 - - - - - - - - 1 Basin, Pour-in - See HOUSING AND COVERS
17 01075.0000 1 Nut, Hex
18 01082.0004 1 Sprayhead, 5-Hole, SST
Not Illustrated
