Bunn C Series - Table of Contents

Page 3
41711.1 052009
Contents
Trouble Shooting .............................................................................................................. 4
Component Access ........................................................................................................ 10
Control Thermostat ........................................................................................................ 10
Electronic Thermostat .................................................................................................... 11
ON/OFF Switch ............................................................................................................... 12
Start Switch (Brew) ........................................................................................................ 13
Solenoid (Inlet) .............................................................................................................. 14
Tank Heater .................................................................................................................... 16
Fill Basin ........................................................................................................................ 16
Tank Heater Switch ........................................................................................................ 18
Thermal Cut-Off ............................................................................................................. 20
Coil/Faucet ..................................................................................................................... 21
Limit Thermostat ............................................................................................................ 22
Recovery Booster ........................................................................................................... 23
Timer (Early Model) ....................................................................................................... 24
Freshness Timer (Early Models)..................................................................................... 25
Digital Brew Timer (Late Model) .................................................................................... 26
Warmer Elements........................................................................................................... 28
Schematic Wiring Diagrams .......................................................................................... 29
