22
FIG. 10 THERMOSTAT TERMINALS
P1448
BLKfromLimit
Thermostat
BLKfromTank
Heater Switch
SERVICE (cont.)
CONTROL THERMOSTAT (cont.)
MECHANICAL THERMOSTAT
TAN to WHI/BRN in
Main Wiring Harness
BLKtoMain
Wiring Harness
WHI to Main
Wiring Harness
BLKtoMain
Wiring Harness
ELECTRONIC THERMOSTAT
29170 091598
