ITEM PART NO. QTY. DESCRIPTION
13
STRAINER AND SOLENOID VALVE PIPING
1 07052.0000 1 Solenoid Valve Assy, 120V (Includes items 2 thru 6)
07052.0002 1 Solenoid Valve Assy, 240V (Includes items 2 thru 6)
2 07072.0000 2 Connector, Male Brass .38” Tube x .25” Male
3 -------------- 1 Solenoid Valve (Not Available. Order item 1)(Refer to
Items 20 &30)
4 01537.0000 1 Washer, Nylon .753” I.D. x 1.006” O.D.
5 07083.1000 1 Air Chamber, Solenoid Valve
6 07051.1000 1 Tube Assy, Inlet - Solenoid to Housing (Includes
Nut and Ferrules)
7 07075.0000 1 Grommet, Inlet Tube Assy 120V
02536.0000 1 Grommet, Inlet Tube Assy 230V
8 01258.0000 1 Valve, Fill/Drain
9 01536.0000 1 Gasket, Fill/Drain Valve
10 07111.0000 1 Fitting, .38” Flare to .75” Hose
11 07109.0000 1 Tube Assy, Manual Refill - Tee to Fill/Drain Valve
12 07117.0000 1 Tube Assy, Strainer to Tee
13 23720.1000 1 Strainer Assy, (Includes items 14, 15 & 16)
14 23723.0000 1 Cap, End
15 23721.0000 1 Screen
16 -------------- 1 Housing, Strainer (Not Available. Order item 13)
17 07112.0000 1 Tee, .38” Male Flare
18 07037.1000 1 Tube Assy, Tee to Solenoid (Includes nuts and ferrules) (Early Model 120/208V,
120/240V, 380V, 440V Brewers and 240V Brewers prior to #U300004095)
19 00603.0000 1 Clamp, .438” I.D.
20 07261.0000 1 Repair Kit, Solenoid (Includes items 7, 21 thru 29)
21 -------------- 1 Spring, Plunger (Not Available. Order item 20)
22 -------------- 1 Plunger Assy (Not Available. Order item 20)
23 07264.0000 1 O-Ring, Bonnet
24 -------------- 1 Seat, Plunger (Not Available. Order item 20)
25 -------------- 1 O-Ring, Plunger Seat (Not Available. Order item 20)
26 -------------- 1 Screen (Not Available. Order item 20)
27 ------------- 1 Gasket, Orifice Plate (Not Available. Order item 20)
28 -------------- 1 Diaphragm, Flow 1.0 GPM (Not Available. Order item 20)
29 01537.0000 1 Washer, Nylon
30 07261.0001 1 Seal Kit, Solenoid (Includes items 7, 21, 23, 24, 25 & 27)
31 28020.0000 1 Coil
32 28021.0000 1 Core Assy Kit (Includes Core, Spring and O-ring)
33 29649.0000 1 Diaphragm and Spring Kit (Includes item 34)
34 29648.0000 1 Spring, Diaphragm
Early Model 120/208V,
120/240V 380V, 440V
Brewers & 240V
Brewers Prior to
#U300004095
28046 080906
(Continued)
