ITEM PART NO. QTY. DESCRIPTION

1 07054.0000 1 Cover,Outlet Box

01318.0000 2 Screw, Round Head #8-32 x .50”

2 07038.0000 1 Terminal Block, Three Pole Red/White/Black

07038.0001 1 Terminal Block, Three Pole Red/Blue/Black

21869.0000 1 Terminal Block, Four Pole

01370.0000 2 Screw, Pan Head #8-32 x .75” (For three pole

terminal blocks)

01322.0000 2 Screw, Round Head #8-32 x 1.50” (For four pole

terminal blocks)

01522.0000 2 Washer

00932.0000 2 Nut, Spacer .25” hex, #8-32 x .375”

3 01531.0000 2 Washer, .875” I.D.

4 07056.0000 1 Elbow, .50” Pull Corner

5 07055.0000 2 Nipple, .50” Chase

6 07053.0001 1 Box, Outlet

01327.0000 1 Screw,Pan Head #10-32 x .375”

7 01309.0000 1 Screw, Pan Head W/Terminal - Ground #10-32 x .375” (120V, 208V, 340V, 440V

Brewers & 240V Brewers prior to #U300004095)

01375.0000 1 Screw, Pan Head - Brass Ground #10-32 x .375”

01512.0000 1 Lockwasher, External Tooth #10

8 00824.0000 1 Decal, Ground (One additional used on single service 240VBrewers #U300004095

and up)

9 27687.0000 1 Bracket, Outlet Box Mounting

01311.0000 2 Screw, Truss Head #8-32 .25”

10 27705.0000 1 Lug, Terminal

02308.0000 1 Screw, Pan Head - Serrated #8-32 x .375”

00970.0000 1 Nut, Keps #8-32 (Single Service Models Only)

OUTLET BOX AND TERMINAL BLOCK

For Single Service

and Scramber

Models

240V Brewer

#U300004095 and up

240V Brewer

#U300004095 and up

For Double Service

Models

28046 031599

Bunn U3 Illustrated Parts Catalog
