ITEM PART NO. QTY. DESCRIPTION
19
THERMOSTATS AND TANK HEATERS
1 07066.1000 2 Tank Heater, 2875W @ 208V
07065.1000 2 Tank Heater, 3325W @ 240V
07185.1000 2 Tank Heater. 3950W @ 208V
07186.1000 2 Tank Heater, 3950W @ 240V
07190.1000 1 Tank Heater, 6000W @ 208V
07191.1000 1 Tank Heater, 6000W @ 240V
07069.1000 2 Tank Heater, 3950W @ 380V
07087.1000 2 Tank Heater, 3950W @ 440V
01315.0000 8 Screw, Truss Head #8-32 x .375’
2 12398.0000 2 Gasket, Tank Heater
3 -------------- 1 Thermostat Assy (Early Brewers w/internal thermostat adjustment. Order late
brewer thermostat kit.)
-------------- 1 Thermostat Assy (Early Brewers w/external thermostat adjustment. Order late
brewer thermostat kit.)
07045.0000 1 Thermostat Kit (Includes items5 & 6)( Late Brewers w/internal thermostat
adjustment) (Replaces early brewer thermostat assy.)
07045.0002 1 Thermostat Kit (Includes items 5 & 6)( Late Brewers w/ external thermostat
adjustment) (Replaces early brewer thermostat assy.)
01315.0000 1 Screw, Truss Head #8-32 x .375” (Early Brewer thermostat mounting)
02328.0003 2 Screw, Pan Head #6-32 x .312” (Late Brewer thermostat mounting)
20762.0000 2 Screw, Binding Head #8-32 x .25 (Late Brewer thermostat terminals)
4 07073.0000 1 Grommet, Thermostat
5 00720.0000 1 Knob, Thermostat Adjustment
6 21238.0000 1 Bracket, Thermostat Mounting ( Early Brewers w/external thermostat adjustment)
27923.0000 1 Bracket, Thermostat Mounting (Late Brewers w/internal & external thermostat
adjustment)
01315.0000 1 Screw, Truss Head #8-32 x .375”
7 29329.1000 1 Thermostat, Limit
Includes one of item 2
28046 021401
