Bunn U3 Illustrated Parts Catalog

ITEM PART NO. QTY. DESCRIPTION
25
1 -------------- 1 Swing Spout Assy. (Brewers W/Out By-Pass) (Includes items 4 thru 6) (Not
Available. Order Item 17)
-------------- 1 Swing Spout Assy. (Brewers W/By-Pass)( Includes item 4 thru 6)(Not Available.
Order item 17)
2 01201.0000 1 Gasket, Swing Spout
3 07026.1002 1 Shield, Swing Spout (Brewers W/Out By-Pass)
07203.1001 1 Shield, Swing Spout (Brewers W/By-Pass)
4 01530.0000 2 Washer, Split
5 06420.0000 2 Pin, Swing Spout
6 07011.0000 1 O-Ring, Swivel Body
7 07149.0000 1 Fitting, Swing Spout Base
01359.0000 3 Screw, Flat Head #8-32 x .38”
00970.0000 3 Nut, Keps #8-32
8 07212.0000 1 Tube, .250” Flare x 4.03” LG (Includes item 10 & 11)(Brewers W/By-Pass &
Plastic Funnel Support)(Refer to item 17)
07212.0001 1 Tube, .250” Flare x 4.44” LG (Includes items 10 & 11)(Brewers W/By-Pass &
SST Funnel Support)(Refer to item 17)
9 00427.0000 1 Valve, Needle (Includes item 10)(Brewers W/By-Pass)
10 00443.0001 1 Nut/Sleeve, .25” Dia Tube (Brewers W/By-Pass)
11 00924.0000 2 Nut, .250” Flare (Brewers W/By-Pass)
12 07092.1003 1 Adaptor, Water By-Pass - Black
01364.0000 1 Plascrew, #6 x .375
13 07027.1003 1 Housing, Water By-Pass - Black
01315.0000 1 Screw, Truss Head Phillips #8-32 x .38”
00908.0000 1 Nut, Hex #8-32
01364.0000 2 Plascrew, #6 x .375” (Brewers W/Plastic
Funnel Support)
14 -------------- 1 Tube, Silicone .312” I.D. x .438” O.D. x 3.0” LG (Order item19)
15 00704.0000 1 Spring
16 -------------- 2 Funnel Support (Not Available. Order item 18)
17 07018.0001 1 Kit, Swing Spout (Includes 1 thru 7)(Brewers W/Out By-Pass)
07019.0001 1 Kit, Swing Spout (Includes items 1 thru 11)(Brewers W/By-Pass & Plastic Funnel
Support)
07019.0002 1 Kit, Swing Spout (Includes items 1 thru 11)(Brewers W/By-Pass & SST Funnel
Support)
18 07098.0001 2 Funnel Support Assy (Includes items 12 thru 16)(Brewers W/By-Pass & Black
Plastic Funnel Support)
07098.0002 1 Funnel Support Assy (Includes items 12 thru 16) (Brewers W/By-Pass & Orange
Plastic Funnel Support)
07098.0003 2 Funnel Support Assy (Includes items 12 thru 16)( Brewers W/By-Pass & SST Funnel
Support)
19 03236.1000 - Tube, Silicone, .312” I.D. x .438” O.D. x 12.0” LG
Refer to item 17
Refer to item 18
Brewers W/Plastic Funnel
Support. Two Additional
used on Brewers W/SST
Funnel Support.
SWING SPOUT AND MOUNTING
28046 121597
