LOWLANDER MK4 MANURE SPREADER – INSTRUCTION & SPARES MANUAL
2.5 Shearbolt Protection.
Only one shearbolt is fitted to the spreader. This is located on the spreader end of the
PTO shaft. The bolt is M10 x 60 grade 6.8 mild steel.
ON NO ACCOUNT MUST A BOLT OF HIGHER GRADE THAN 6.8 TENSILE STRENGTH BE
FITTED.
2.6 Key greasing points
KEY GREASE POINT
1 ALL BEARINGS IN DRIVE LINE
2 FRONT SHAFT
3 PTO KNUCKLES
4 REAR SHAFT
5 BEARINGS TOP OF AUGERS (GREASE POINT O/S ON TURRET)
2.7 Jacking Points
Jack the spreader up on the axle or on the base of the auger turret pressings at the rear
to replace a wheel.
