LOWLANDER MK4 MANURE SPREADER – INSTRUCTION & SPARES MANUAL
Page
28
3.4 FLOOR DRIVE GEARBOX MK4 75/90/105/105C/120 – B3105 PARTS LIST
KEY QTY PART No. DESCRIPTION
1 1 B3203 CASING
2 1 B3228 SLEEVE M50
2 1 B3229 SLEEVE M60 (W.B BEATERS & 20mm CHAINS )
3 1 B4099 CIRCLIP
4 1 B3231 GEAR
5 2 BR320 BEARING
6 2 B4015 CIRCLIP
7 1 B3237 PINION SHAFT
8 2 B2271 KEY
9 1 B3234 GEAR
10 2 BR350 BEARING
11 3 B4006 CIRCLIP
12 1 B3232 PINION SHAFT
13 1 B2270K KEY
14 1 B3238 CROWN BEVEL
15 1 B3478 SPACER
16 2 BR375 BEARING
17 2 B4002 CIRCLIP
18 1 B3233 PINION SHAFT
19 1 BR310 BEARING
20 1 B4019 CIRCLIP
21 2 B3997 BREATHER PLUG
22 2 B3995 SIGHT GUAGE
23 2 SL255 CAP SEAL
24 2 SL265 CAP SEAL
25 2 SL200 SEAL
26 1 B3222 GASKET
27 1 B3218 COVER PLATE
28 8 73030/1 BOLT
29 1 B3226 GASKET
