LOWLANDER MK4 MANURE SPREADER – INSTRUCTION & SPARES MANUAL
Page
42
4.4 GEARBOX 540/360 STANDARD PART No. B3172 (SRT12) PARTS LIST
KEY QTY PART No. DESCRIPTION
1 1 B3404 CASING
2 1 B3410 EXTENSION
3 1 B3494 GASKET
4 4 BR175 BEARING
5 1 B3440 SHAFT
6 2 B3510 NUT LH THREAD
7 3 B3520 WASHER
8 1 SL165 SEAL
9 1 B3400 CASING R.H
10 2 B3492 GASKET
11 1 B4014 CIRCLIP
12 1 BR410 BEARING
13 2 B3442 SHAFT
14 2 B3480 SPACER
15 2 BR180 BEARING
16 2 BR405 BEARING
17 2 B3482 SLEEVE
18 2 B3420 TOP PLATE
19 2 SL195 SEAL
20 2 B3490 GASKET
21 2 B4007 CIRCLIP
22 1 B3402 CASING
23 1 B3446 SHAFT
24 1 B4020 CIRCLIP
25 1 B3512 NUT R.H THREAD
26 2 SL275 CAP SEAL
27 1 B3998 PLUG
28 1 B3996 SIGHT GLASS
29 1 B3990 DRAIN BUNG
30 22 73125 BOLT
31 12 73124 BOLT
32 2 B3939 O -RING
33 3 B3454 PINION
34 3 B3464 GEAR
35 2 B3420 DRIVE ASSEMBLY
36 1 B3409/1 NOSE CONE ASSEMBLY
