Burdick Atria 3000 - Parts Lists & Exploded Views

Parts Lists & Exploded Views
Atria Service Manual 4-9
Parts Lists & Exploded Views
To locate components, refer to the figure on page 4-10 and this parts list:
Item # Part # Quantity Description
1
650-1421-00 1 Top Enclosure Assembly, Service
2
215-0223-00 4 Screw
3
650-1414-00 1 Paper Door Assembly, Service
4
650-1464-00 1 Battery Cover Assembly, Service
5
146-0126-00 1 Battery Pack, NiMH
6
650-1420-00 1 Queue Sensor Assembly, Service
700257 1 Nylon Screw
703117 1 Nylon Nut
7
650-1416-00 1 Paper Drive Assembly, Service
8
215-0223-00 2 Screw
9
175-1566-00 1 Keyboard Cable
10
175-1570-00 1 Display Cable
11
175-1571-00 1 Power Supply Cable
12
650-1418-00 1 I/O Cover Assembly, Service
13
215-0223-00 2 Screw
14
650-1441-00 1 I/O Assembly, Service
215-0223-00 2 Screw
15
174-1677-00 1 Programmed Compact Flash Card
16
211-0466-00 6 Screw
17
671-1002-04 1 Front End Digital Board Assembly,
Service
18
211-0466-00 5 Screw
19
671-1268-00 1 Power Supply Board, Service
20
650-1419-00 1 Power Supply Cover Assembly,
Service
175-1572-00 1 Ground Wire
21
175-1573-00 2 Ground Wire
22
175-1603-00 1 Ground Wire
23
650-1417-00 1 Bottom Assembly, Service
