6. TECHNICAL DATA
Conditions of use
Ambient temperature
(operating)
-15 °C to +60 °C
Air humidity < 80%, non condensated
Protection rating IP65, female connector wired,
plugged and tightened
Conformity to standards and
directives
The device conforms to the EC directives through the
following standards:
• EMC: EN 61000-6-2, EN 61000-6-3
• Pressure: The S030 fitting complies with article 3 of §3
from 97/23/CE directive.
Acc. to pressure directive 97/23/CE, the fitting can only
be used in the following cases (depending on the max.
pressure, the DN of the pipe and the fluid):
Type of fluid Conditions
Fluid group 1 § 1.3.a only DN25
Fluid group 2 § 1.3.a DN 32
or DN > 32 and PNxDN 1000
Fluid group 1 § 1.3.b PNxDN 2000
