17
Materials
Part Material
Housing, male fixed
connector
PC
Female connector
type 2508 / screw /
seal
PA / Stainless steel / NBR
Fitting S030 refer to the operating instructions of the
fitting used.
Electrical data
Supply voltage
• Hall version
• Hall Low Power
version
• 12-36 V DC, filtered and
regulated
• 12-36 V DC, via transmitter
the device is connected to
Dielectric strength 2300 VAC
Current consumption
• Hall version
• Hall Low Power
version
• 30 mA max.
• 0,8 mA max.
Protection against
polarity reversal
yes
English
17
