14
Type of fluid Conditions
Fluid group 2 § 1.3.b DN200
General data
Pipe diameter DN6 to DN65
The appropriate diameter is deter-
mined using the flow rate / DN / fluid
velocity graphs.
Pressure class Depends on the material of the fitting
used and on the fluid temperature:
refer to the operating instructions of
the fitting used.
Fluid temperature
• with fitting S030 in
metal or PVDF
• with fitting S030
in PP
• with fitting S030 in
PVC
The fluid temperature may be restricted
by the fluid pressure: refer to the ope-
rating instructions of the fitting used.
• -15 to +100 °C
• 0 to +80 °C
• 0 to +50 °C
Type and data of the
fluid
refer to the operating instructions of
the fitting used.
