Burley BEE - IV. Unfolding and Folding Your Burley Bee

BEE
ASSEMBLY & USE
5
Opening Your Trailer
For removing wheel:
while pressing button,
slide wheel out of the axle
receiver. Release button.
While pressing rubber
button, insert wheel axle
into axle receiver, and
then release the button.
Pull firmly on wheel to
confirm the axle is fully
engaged.
1
1
2
Insert the the wheel guard into the reciever. Slide the
wheel guard back until you hear it click into place.
Repeat for other side.
Installing the Wheel Guards
Attaching & Removing
the Wheels
Lift front frame at rear.
1
Raise the rear frame tube until the tubes
sit together on the plastic saddles.
2
Lock bars together by pushing
down on the yellow latches.
3
Opening Your Trailer
4.
WARNING
CARE MUST BE TAKEN WHEN FOLDING AND UNFOLDING TO PREVENT FINGER ENTRAPMENT.
note
Damage to windows can occur if
trailer is folded with wheels installed.
Remove passengers and
cargo, and then remove the
tow bar and both wheels.
From the rear of the trailer, lift the
cover. While depressing the latch
release button, lift the yellow latches.
Push the rear frame at the
lower bend to fold flat.
1
2
3
Closing Your Trailer
4.
WARNING
CHECK THAT THE FRAME LATCHES ARE PROPERLY ENGAGED BEFORE USING TRAILER.
4.
note
If right latch will not rotate freely,
depress button to allow latch to
rotate forward.
