Burley BEE - Installation and Use of the Cover; Tongue Installation and Operation

BURLEY.COM
6
ASSEMBLY & USE
Installing the Tow Bar
Removing the Tow Bar
Securing the Cover
While depressing the button, slide
the tow bar into the tow bar receivers
until hole A with hole B. The red
safety strap bracket should be flush
with the front of the reciever.
Insert the retaining pin from the
top through the aligned holes.
Ensure that the retaining pin is
locked properly as shown above
1
2
3
A B
Clip the receiver safety strap to the
D-ring on the trailer frame.
4
Remove the retaining pin,
and unclip the safety strap
1
While depressing button,
remove the tow bar
2
Attach cover to trailer by using the
snaps at the top of the trailer.
1
Attach the velcro at the rear and slip the cover D-rings
over the hooks at the front corners of the trailer
2
