12
ASSEMBLY & USE
ASSEMBLY & USE
for TOC, do not delete. box must not extend to pages edges. don't forget to also add it to your pages panel
Bike Trailer Mode: Always rotate the
handlebar forward when using as a bike
trailer. The handlebar should be horizontal
and parallel to the ground, such that
the mark on the handlebar is aligned
with the bolt that attaches the cover.
Stroller Mode:
Rotate the handlebar
to serve as a handlebar while using
as a stroller. Open lever to rotate
and close lever to lock in place.
To lock the brake, slide the lever
to the right. To release the brake,
slide the lever to the left.
Fabric loops are located on the back of
the trailer fabric and should be used to
attach additional lights and/or reflectors.
Slip the cover D-rings over the hooked
corners of the tow bar receivers.
Depress the yellow button and slide the flag
pole into hole on flag holder. To release, depress
the yellow button and lift flag pole out.
1
2
1
1
1 1
Adjusting the HandlebarLocking the Brake
Installing Additional Lights Securing the Cover Installing the Flag
note
The handlebar lever tension is
optimally adjusted from the factory. If
the handlebar slips when lifting up or
pushing down – or if it makes excessive
noise when rotating – the lever tension
can be fine-tuned. Release the lever,
squeeze the handlebar tube together
and turn the barrel nut in 180 degree
increments. Adjust the barrel nut to
desired tension.
WARNING
ALWAYS USE THE
JOGGING TETHER WHEN
USED AS A STROLLER.
