ENCORE X
ASSEMBLY & USE
9
ASSEMBLY & USE
for TOC, do not delete. box must not extend to pages edges. don't forget to also add it to your pages panel
WARNING
CARE MUST BE TAKEN WHEN FOLDING AND UNFOLDING TO PREVENT FINGER ENTRAPMENT.
note
Damage to windows can
occur if trailer is folded with
wheels installed.
Lift front frame at rear.
Remove passengers and
cargo, and then remove the
tow bar and both wheels.
Pull rear frame tube towards you.
From the front of the trailer,
lift the cover then press the
yellow release latches and pull
the rear frame through.
▼
Squeeze frame tubes together with
both hands to latch securely in place.
Fold flat.
1
1
2
2
3
3
Opening Your Trailer
Closing Your Trailer
For removing wheel: while pressing
button, slide wheel out of the
axle receiver. Release button.
While pressing rubber button, insert wheel
axle into axle receiver, and then release the
button. Pull firmly on wheel to confirm the
axle is fully engaged.
1
2
Attaching & Removing
the Wheels
