9
Module input The module input (25) may be equipped alternatively with 4 different modules:
•
••
• LINE module
The standard version of the preamp is equipped with a LINE module. In this case the
module input is an unbalanced high-level input.
NOTICE: Subsequent installation of other modules must only be done by your authorized
dealer or by Burmester Audiosysteme GmbH.
•
••
• PHONO MC module
With a PHONO MC module the module input is a balanced PHONO MC input to connect
a record player with moving coil pickup (no high output MC).
If your pickup has an unbalanced output, the balanced PHONO MC input can be
converted to unbalanced mode by using XLR-RCA adapter plugs.
The input resistance and the amplification of the PHONO MC module can be attuned to
your pickup with the MC SETUP. For detailed instruction please refer to the chapter THE
SETUP MENUS / MC SETUP.
The PHONO SETUP offers an automatic channel calibration, which verifies the channel
equality of your pickup and adjusts it, if necessary. The PHONO SETUP also offers the
chance to switch on a subsonic filter to eliminate low frequency noise.
The pinning of the balanced PHONO MC input is: PIN1=GND, PIN2=NEG, PIN3=POS.
On request the PHONO MC modules and the adapter plugs are available at your local
dealer.
NOTICE: Subsequent installation of other modules must only be done by your authorized
dealer or by Burmester Audiosysteme GmbH.
•
••
• PHONO MM module
With a PHONO MM module the module input is a balanced PHONO MM input to connect
a record player with moving magnet pickup or high output moving coil pickup.
If your record player has an unbalanced output, the balanced PHONO MM input can be
converted to unbalanced mode by using XLR-RCA adapter plugs.
The input capacitance and the amplification of the PHONO MM module can be attuned to
your pickup with the MM SETUP. For detailed instruction please refer to the chapter THE
SETUP MENUS / MM SETUP.
The PHONO SETUP offers an automatic channel calibration, which verifies the channel
equality of your pickup and adjusts it, if necessary. The PHONO SETUP also offers the
chance to switch on a subsonic filter to eliminate low frequency noise.
The pinning of the balanced PHONO MM input is: PIN1=GND, PIN2=NEG, PIN3=POS.
On request the PHONO MM modules and the adapter plugs are available at your local
dealer.
NOTICE: Subsequent installation of other modules must only be done by your authorized
dealer or by Burmester Audiosysteme GmbH.
