OPERATION MANUAL
AC OUTLETSFILTERS
The device is equipped with eight AC outlets for connecting hi-fi equipment; these
are divided into four groups. The markings on the rear panel indicate which filters
need to be connected to which AC outlets (FILTER). If you wish to connect the power
filters to the AC outlets differently, please contact your authorised dealer.
The standard version of the device offers unfiltered mains voltage for the AC outlet
groups MAINS OUT 3 (17, 18) and MAINS OUT 4 (20, 21). The AC outlets in the
groups MAINS OUT 1 (11, 12) and MAINS OUT 2 (15, 16) have separate power filters.
The DC compensation affects all eight AC outlets.
The maximum output per AC outlet must not exceed 2,000 W @ 230 V, 1,550 W @
120 V and 1,300 W @ 100 V. The maximum permissible total output for all connected
devices is listed in the technical specifications at the end of this operation manual
(maximum power output).
NOTES ON CONNECTION
In order to optimise the operation of your 948 power conditioner, we recommend
connecting your audio equipment as follows (other combinations are also possible):
When using very powerful amplifiers with a continuous power consumption of more
than 500 W, we recommend connecting these directly to the parallel wall outlet.
Because it runs in parallel, the 948 power conditioner will also affect this outlet,
and thus all the devices connected to it.
MAINS OUT 1 (FILTER1)
Preamplifiers, phono preamplifiers,
record players, FM tuners
MAINS OUT 2 (FILTER2)
Digital devices, e.g. CD players, DVD players,
digital-to-analogue converters, dig. tuners
MAINS OUT 3 and 4 All types of amplifiers, incl. subwoofers
