70
Figure 60: Boiler Flueway Cleaning
Table 13: Pilot Burner Location
.oNledoMrelioB
neewteBdetacoLtoliP
*srenruB
B5085&4
B6086&5
B7087&6
B8087&6
B9087&6
B0188&7
tnorfmorfdeweivsathgirottfelderebmunsrenruB*
.reliobfo
F. Clean Combustion Chamber by vacuuming. Exercise
care to avoid damaging Base Insulation.
G. Install Burners by reversing procedures used to
remove burners. Verify Main Burners are properly
located on support bracket in Base Rear Panel, seated
on Main Burner Orifices, and secured with hitch pin
clips. Verify Main Burner with Pilot Bracket is in
proper location. See Table 13.
H. Lubrication. Manufacturers Instruction should be
followed on all parts installed on boiler requiring
lubrication. This includes type of lubricant to be used,
frequency of lubrication, and points to lubricate.
I. Check operation. Refer to Section VIII: System Start-
up.
