Aenon!Makesurethatno
aming and smoldering pellets
agocleanwithavacuumcleaner
andtemperaturesurfacesisless
than40°C
9.3.1 Cleaning and maintenance of
suconfan
Diagram 11
Unmount the ash container as described
in the manual instruction.
Diagram 12
Unmount by using the “+” screwdriver the
four screws size M5. Aer that unmounts
the revision cover.
Diagram 13
Aer the revision cover is unmounted,
there is direct access to the fan turbine.
Do detailed cleaning by using brush and
vacuum cleaner of the ash on the fan
turbine as well as the zone around it. Aer
the zone is well cleaned, put the revision
cover back and clamp well the four screws
size M5.
9.3.2 Cleaning and maintenance of
theFumeexhausttube
Diagram 14
-Open the front revision cover, pointed in
scheme 14.
