TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
For general safety consideraons, we
recommend that the boiler be placed on
a foundaon made of class A material, see
table 2.
2. PRODUCT DESCRIPTION
Ecological and highly-ecient pellet
boiler Pell Easy is designed for ring
wood-pellets. The mantle fully covers
the combuson chamber. Eciency rate
reaching 92%. Approved in accordance
with EN 303-5, class 5.
2.1.DesignstructureofboilerPelleBurn.
Restingular body design is made of high-
quality boiler steel sheets with thickness
of 4 mm for the combustion chamber and
3 mm for the water mantle.
• Ecological. A high-end pellet boiler. The
wood-pellets used for fueling the boiler
are a renewable fuel with minimum
carbon emissions and ulmate burning
eciency.
• Automated. All boiler funcons are fully
automated – no human intervenon is
needed for the normal operaon of the
boiler. Owing to an improved algorithm
with oponal adjustment of a wide
variety of parameters, the system may
be nely tuned to any parcular heang
system to achieve opmum eciency
and fuel consumpon.
Controllerfuncons:
1)fully automated ignion and pellet
feed;
2)burnerself-cleaningfunction;
3)controls the operaon of central
heangcirculaonpump;
4)controls the operaon of DHW
(domeschotwater)pump;
5)controlsbyroomthermostat;
6)uegassensor;
• Efficient. To keep from losing heat into
the ambience, the boiler is insulated on
the outside by 50 mm high-temperature
wool. With its inteligent state-of-the-
art combustion control system the Pell
Easy boiler achieves efficiency rate of as
much as 92%
2.2. Safety devices of pellet boiler-and-
burner
A complex of safety devices provide for
the safety of the appliance. Air-feed fan,
step –regulated, controls the combuson
according to energy needs and is
maintained in opmal working order.
Independent STB thermostat shut-o the
burner and shut o the fuel feeding in
the combuson chamber in case of rising
boiler temperature.
• Thermostatic protection (80°С). The
thermostatic protection is fitted on the
auger chute. When the surface of the
feeder chute reaches 80°С, the control
stops the feeding of pellets into the
burner and signals for fault.
• Fuse. In case of electrical fault in the
system of the burner (short circuit,
current overload, etc.), the overload is
borne by the electrical fuse ed on the
main control panel of the burner (10 А).
• Power interrupon. Innovave
controller. In case of power interrupon,
all parameter sengs are stored in the
memory of the controller. Upon the
