Sensor
excitation
[V]
Output
[mV/V]
Calculated
bridge
voltage
[mV]
Output
(reference)
[V]
Calculated
gain
Stage 1
Set gain
(decimal)
Stage 2
Set gain
(0.25…63)
Stage 3
Set gain
(2/4/6/8)
5
0.1
0.5
10
20.000.00
100
50
4
5
0.2
1
10
10.000.00
100
50
2
5
0.3
1.5
10
6.666.67
100
33.25
2
5
0.4
2
10
5.000.00
100
25
2
5
0.5
2.5
10
4.000.00
100
20
2
5
0.6
3
10
3.333.33
100
16.75
2
5
0.7
3.5
10
2.857.14
100
14.25
2
5
0.8
4
10
2.500.00
100
12.5
2
5
0.9
4.5
10
2.222.22
100
11
2
5
1
5
10
2.000.00
100
10
2
5
1.1
5.5
10
1.818.18
100
9
2
5
1.3
6.25
10
1.600.00
100
8
2
5
1.4
7
10
1.428.57
10
35.75
4
5
1.5
7.5
10
1.333.33
10
33
4
5
1.6
8
10
1.250.00
10
62.5
2
5
1.7
8.5
10
1.176.47
10
58.75
2
5
1.8
8.75
10
1.142.86
10
57
2
5
1.9
9.5
10
1.052.63
10
52.5
2
5
2
10
10
1.000.00
10
50
2
5
2.25
11.25
10
888.89
10
44.5
2
5
2.5
12.5
10
800.00
10
40
2
5
2.75
13.75
10
727.27
10
36.25
2
5
3
15
10
666.67
10
33
2
Table 5: Gain setting for strain-gauge full-bridge sensors
