Busch-Jaeger 1094 U - Technical data

Technical data
Product manual 2CKA001473B8289
│11
5 Technical data
Nominal voltage 1094...
1095...
1097...
230 V AC ±10%, 50 / 60 Hz
1096... 24 V AC ±10%, 50 Hz
Switching capacity 1094...
1095 U
1095 UTA
10 (A) A, 230 V AC
1096... 16 (2) A, 230 V AC
1096... 1 (1) A, 24 V AC
1096... 5 (2) A, 230 V AC
Connecting terminals 1094...
1095 U
1095 UTA
1096...
1097...
1.5 mm² - 2.5 mm²
1095 UF 2 x 2.5 mm² – 1 x 4 mm²
Temperature adjustment range 1094...
1095 U
1095 UTA
1096...
1097...
1 - 6 (5 - 30°C)
1095 UF 1 - 6 (10 - 50°C)
Temperature reduction 4 K
Switching temperature difference ±0.5 K
Protection type IP 20 (EN 60529)
Remote sensor 1095 UF NTC 10 kΩ / 25°C
Sensor line length 1095 UF 4 m
Ambient temperature range 0 - 30°C
Mode of operation (DIN EN
60730-1)
1B
Degree of contamination (DIN EN
60730-1)
2
Rated surge voltage (DIN EN
60730-1)
4000 V
