Maintenance | 8
Instruction Manual FOSSA FO 0015 A - FO 0035 B_EN_en 23 | 40
● Unscrew the six screws of the fixed scroll and slowly remove with care the fixed scroll.
Description
1 6 mm hex key (ideally T-handle)
● Remove the used tip seals (pos. 8) from its groove by the help of a small pointed tool and the O-
ring (pos. 26).
Description
1 Fixed scroll 2 Tip seal, pos. 8
3 O-ring, pos. 26
