8 | Maintenance
24 | 40 Instruction Manual FOSSA FO 0015 A - FO 0035 B_EN_en
Description
1 Tip seal, pos. 8 2 Moving scroll
● Wipe all spirals with a soft, lint-free cloth, impregnated with alcohol, including the tip seal grooves
● Make sure that there is no remaining debris in the scroll parts.
Description
1 Clean-up spirals
Set and adjust the new tip seals in the groove by starting from the center. Make sure that the tip
seals are correctly assembly in the holding claws. Use a cutter knife to adjust the tip seal length.
Make sure that the tip seals are fully pushed in the groove with the fingers.
