20
11. LUGGAGE RACK
TURBO+2
The luggage rack for the Turbo+2 consists of 4 rails. The luggage rack has a maximum
weight rating of 75 pounds, spread evenly over the 4 rails.
QUANTUM
The luggage rack for the Quantum consists of 4 rails. The luggage rack has a maximum
weight rating of 75 pounds, spread evenly over the 4 rails.
ROADSTAR
The luggage rack for the Roadstar consists of a chrome tubular steel rack. The luggage
rack has a maximum weight rating of 25 pounds.
12. INTERIOR LIGHT
The interior light is run via its own wire in the primary harness. During a typical
installation, it is connected into the running lights on the motorcycle. This way, if the
light is left on but the ignition is turned off, the light will go off. The light can be hooked
to the accessory terminal or directly to the battery, but must be fused and adds
opportunity for battery drain if the light is left on.
CAUTION: The interior light should be turned off when not in use to avoid unnecessary
battery discharge.
WARNING: IF LEFT ON FOR EXTENDED PERIODS, THE INTERIOR LIGHT
LENS CAN BECOME EXTREMELY HOT. DO NOT TOUCH THE LENS AND DO
NOT ALLOW ITEMS TO MAINTAIN CONTACT WITH THE LENS, AS THEY
MAY MELT OR BE DAMAGED.
13. WIRE HARNESS COLOR CODES
Following are the primary wiring harness functions identified by color.
GREEN: RUNNING & TAILLIGHTS
WHITE: CHASSIS OR BATTERY GROUND
BLUE: BRAKE LIGHTS
YELLOW: RIGHT TURN SIGNAL
