22
16. LIGHTING ACCESS & SERVICE
Each Bushtec model features unique and distinctive lighting styles which require
different methods of accessing bulbs for replacement. On the Quantum Sport and
Quantum “GL” models, the taillight recess cover must be removed to facilitate changing
of taillight bulbs.
REMOVAL OF TAILLIGHT RECESS COVER
On the Quantum Sport and Quantum “GL” models the taillight housing recess is covered
with a removable cover. The cover is held in place with two screw fasteners. The panel
can be removed by supporting the panel and loosening and removing each fastener. Once
the fasteners are removed, the panel will be loose. Note engagement hole placement and
that the interior light, if so equipped, is mounted on this panel and plugged into the
harness. If it is necessary to fully remove the cover and unplug the light, note the
connection locations and color codes.
TAILLIGHT & TURNSIGNAL BULB REPLACEMENT
TURBO +2
Taillight and turnsignal- From the outside of the trailer using a Phillips head screw driver,
loosen and remove the screws that hold the corresponding lens in place to access the
bulb.
ROADSTAR
Taillight and turnsignal- From the outside of the trailer using a Phillips head screw driver,
loosen and remove the screws that hold the corresponding lens in place to access the
bulb.
QUANTUM SPORT
Taillight and turnsignal- Open the trailer and remove the taillight recess cover as
described above. The bulb base holders twist out of the back side of the housing.
QUANTUM “GL”
Taillight and turnsignal- Open the trailer and remove the taillight recess cover as
described above. Remove the three nuts from the studs in the light housing base and
carefully remove the light housing from the recess. The bulb holders twist out of the
back side of the housing. Reapply a sealant around threaded studs and wiring hole when
reinstalling, pulling any excess harness back into the body, out of the recess.
