12.2 Units with a standard design *
Bewazon Ozone Unit VULW Type 70 140 210 280 350
Ozone generator Quantity 1 2 3 4 5
Rated ozone output according to DIN 19627 g/h 70 140 210 280 350
Ozone concentration as per DIN 19627 g/m³ 20
Gas used Air
Air quantity Nm³/h 3.5 7.0 10.5 14.0 17.5
Operating gas pressure bar, rel. -0.1 to 0.0
Ambient temperature °C 5-30
Max. relative humidity for devices with:
Standard design, at max. 30°C
Tropical design, at max. 40°C
%
%
60
60
Max. absolute humidity for devices with:
Standard design, at max. 30°C
Tropical design, at max. 40°C
g/Nm
3
g/Nm
3
20
40
Protection class IP53
Number of dryers 2
Desiccantperdryer(multi-layeredlling) kg 12 12 12 12 12
Transformers Pieces 1 1 1 1 1+1
Transformer capacity kVA 3 6 9 12 6+9
Specicenergyofstainlesssteelozonegenerator
at 50/70/100% of the rated ozone production capacity Wh/g 12 / 13 / 17
Operation with
50%
70%
100%
Ozone production
capacity
Electrical power consumed with
stainless steel ozone generator inclu-
ding air drying
kW
kW
kW
0.56 1.12 1.68 2.24 2.80
0.78 1.55 2.33 3.11 3.89
1.33 2.66 3.99 5.32 6.65
SpecicenergyofPVCozonegenerator Wh/g ≤25
Ozone generation stainless steel/PVC, adjustable in steps 16 / 14
Operating voltage 3/N/PE ** V/Hz 400 (415)/50/60
Max. current consumption per phase *** A 13 16 25 32 32
External overcurrent protection A, slow 25 35 50 63 63
Coolingwaterowat4-17°CWT L/h 100 200 300 400 500
Cooling water connection d (DN) 20(15) 20(15) 20(15) 20(15) 20(15)
Cooling water pressure, stainless steel / PVC bar 8 / 1
Ozone connection d (DN) 20(15) 20(15) 25(20) 25(20) 32(25)
Width, dryer cabinet mm - - 800 800 800
Width, control cabinet mm - - - - 1200
Width, ozone tubing cabinet mm - - - 800
Width, control and ozone tubing cabinet mm - - 1200 1200 -
Width, total unit mm 1000 1000 2000 2000 2800
Height, plus 100 mm for connections mm 2100 2100 2100 2100 2100
Depth, plus 1000 mm clearance for door mm 600 600 600 600 600
Weight excl. packaging, stainless steel, approx. kg 530 620 900 1000 1250
Weight excl. packaging, PVC, approx. kg 510 580 840 920 1150
PNR Unit with stainless steel ozone generator 6-202196 6-202197 6-202198 6-202199 6-202200
PNR Unit with PVC ozone generator 6-202208 6-202209 – – –
* a)Multi-circuitsystems:Deviationsfromindividualspecicationspossible.
b) Tropical units: Air humidity and air temperature requirements for the installation area are displayed
** Max. 13 to 14 levels are available at a mains frequency of 60 Hz.
*** Theindividualphasesdrawdi󰀨erentcurrents.
