BWT Multipur AP Series User Manual

1717
1717
17
GBGB
GBGB
GB
MultipurMultipur
MultipurMultipur
Multipur
TypeType
TypeType
Type
65 A 65 A
65 A 65 A
65 A
80 A80 A
80 A80 A
80 A
Nominal connection width DN 65 80
Flow capacity at ∆p = 0,2 bar m
3
/h 22 36
Micron rating µm 100 or 200
Nominal pressure (PN) bar 16
Operating pressure p
o
min./max. bar 2.5/14
Minimum pressure behind filter (for backwashing)bar 2.5
Rinsing water volume at 4 bar l 30
Rinsing water flow 1.7 l/s (m
3
/h) 1.7 (6.0)
Water temperature / ambient temperature °C 5 - 30 / 5 - 40
Mains connection V/Hz 230/50
Operating voltage V- 12
Power consumption, max. W 12
Protection IP 54
Flange connection according to DIN 2501, Part 1
Circlediameter / flangebore mm 145 / 18 160 / 18
L Face to face length mm 220
H
1
/ H
2
/ H
3
Height, approx. mm 230 / 320 / 380
Drainage connection, min. DN 50
Operating weight, approx. kg 15 18
Product number (100µm)Product number (100µm)
Product number (100µm)Product number (100µm)
Product number (100µm)
6 - 3720176 - 372017
6 - 3720176 - 372017
6 - 372017
6 - 3720186 - 372018
6 - 3720186 - 372018
6 - 372018
Product number (200µm)Product number (200µm)
Product number (200µm)Product number (200µm)
Product number (200µm)
6 - 3720196 - 372019
6 - 3720196 - 372019
6 - 372019
6 - 3720206 - 372020
6 - 3720206 - 372020
6 - 372020
TT
TT
T
echnical dataechnical data
echnical dataechnical data
echnical data
Ø 50Ø 50
Ø 50Ø 50
Ø 50
HH HH
H
22 22
2
HH HH
H
11 11
1
LL
LL
L
DN 65DN 65
DN 65DN 65
DN 65
DN 80DN 80
DN 80DN 80
DN 80
HH HH
H
33 33
3
