BYD B-BOX 2.5 - B-BOX Configuration List with GOODWE ES-On;Off Grid; B-BOX Configuration List with GOODWE BP-On Grid; B-BOX Configuration List with Victron Multiplus;Multigrid-On;Off Grid

Page 16
SI 4.4M
≥8
≥2
SI 6.0H
≥12
≥3
SI 8.0H
≥12
≥3
Remark: Maximum B-Plus quantity is 32,Cabinet quantity is 8.
8.2 B-BOX configuration list with GOODWE ES-On/Off grid
1 Phase on Grid
Inverter Type
B-Plus 2.5
Cabinets
4.6kW
≥1
1
≥1
1 Phase off Grid
Inverter Type
B-Plus 2.5
Cabinets
4.6kW
≥2
≥1
Remark: Maximum B-Plus quantity is 32,Cabinet quantity is 8.
8.3 B-BOX configuration list with GOODWE BP-On grid
1 Phase on Grid
Inverter Type
B-Plus 2.5
Cabinets
2.5kW
≥1
≥1
Remark: Maximum B-Plus quantity is 32, Cabinet quantity is 8.
8.4 B-BOX configuration list with Victron Multiplus/Multigrid-On/Off grid
1 Phase on Grid
Inverter Type
B-Plus 2.5
Cabinets
3KVA
≥1
≥1
5KVA
≥1
≥1
1
This configuration is only for self consumption application.
