DA3N User's Manual
13
❻❼
OPT2/OPT3
Connect to any digital audio device using an optical ber cable with a
TOSLINK connector. This input supports sampling frequencies from
32kHz to 96kHz.
❽
AES/EBU
Connect to any digital audio device using a 110Ω balanced XLR cable
(1=GND, 2=Hot, 3=Cold). This input supports sampling frequencies from
32kHz to 192kHz.
❾
USB2
Connect to a computer using a USB cable with a B plug. This input
supports sampling frequencies from 32kHz to 96kHz but not 88.2kHz
which is automatically upsampled to 96kHz.
❿
MCK 44.1kHz
44.1kHz master clock input jack with a BNC connector. Connect to an
external clock generator using a BNC (75Ω) cable. When the external
master clock is supplied "M" is displayed. When DA3N is connected with
a CD transport via SUPERLINK ( SL1
or SL2), the CD transport is
under the same master clock control.
Note: External master clock does not work at the other connections than
SUPERLINK.
SL1(SUPERLINK BNC)
CEC’s proprietary SUPERLINK interconnection via BNC cables. There
are four terminals: DATA, LRCK, MCK and BCK which should be
connected accordingly via 75Ω coaxial BNC cables supplied with DA3N.
You may connect with CEC TL1N and TL3N. When the other BNC
cables are used, make sure to select high quality BNC cables with 75Ω.
Sampling frequency is xed at 44.1kHz.
SL2(SUPERLINK D-SUB)
CEC’s proprietary SUPERLINK interconnection via D-Sub-9pin cable.
Connect a CD transport equipped with a D-Sub-9 pin SUPERLINK
output like TL51 series.
Note: Common D-Sub-9pin cable at computer world cannot be
recommended. You may consult with your dealer for CEC recommended
cable.
AC LINE
Connect the AC power cord supplied with DA3N.
