C.T.M. HS-665 User Manual

Instruction Booklet6-Series
12
Rear Shroud is removable by lifting the Rear Shroud up. (See Fig. 16)
Disconnect Wire Harness. (See Fig. 17)
Release two Guide Pins to separate Front and Rear Sections. (See Fig. 18)
With one hand on rear frame and other on seat post as handheld, detach Front and Rear
Sections. (See Fig. 19)
By removing the front basket and adjusting the tiller down by using the Tiller Angle
Adjustment Lever you should be able to place all parts in the trunk and part of the Rear
Seat.(See Fig. 20 & 21 & 22)
Figure 17
Figure 17
Figure 16
Figure 16
Figure 22
Figure 22
Figure 19
Figure 19
Figure 18
Figure 18
Figure 21
Figure 21
Figure 20
Figure 20

C.T.M. HS-665 Specifications

General

Brand	C.T.M.
Model	HS-665
Category	Scooter
Language	English
