C.T.M. HS-665 User Manual

Instruction Booklet6-Series
11
DISASSEMBLING YOUR SCOOTER
Taking apart your scooter enables you to save space when keeping it in storage
or to carry it along in your vehicle when going away from home. Having scooter
disassembled is easier than ever since no tools are required.
Please follow these steps :
Seat is removable by releasing the Seat Adjusting Lever (F) and then lift off. (See Fig. 10)
Rear Shroud Cover is removable by lifting up. (See Fig. 11)
Then disconnect Rear Turnsignal Wire. (See Fig. 12) and remove front Battery Cover.
(See Fig. 13)
Unplug Battery Wire (See Fig. 14) and untie Battery Fixing Velcro to remove Batteries.
(See Fig. 15)
Figure 11
Figure 11
Figure 10
Figure 10
F
Figure 13
Figure 13
Figure 12
Figure 12
Figure 15
Figure 15
Figure 14
Figure 14
