C.T.M. HS-730 User Manual

Instruction Booklet7-Series
H
J
I
K
M
L
10
Remove Rear Hood (H) by pushing the end forward. (See Fig. 10)
Release two Locking Pins (I) to separate front and rear units.
(See Fig. 11)
Figure 10
Figure 10
Figure 11
Figure 11
With one hand on Rear Frame (J) and other on Seat Piller (K) as Hand hold. detach front
and rear sections. (See Fig. 12)
By removing the Front Basket (L) and adjusting the tiller down by using the Tiller Angle
Adjustment (M) you should be able to place all parts in the trunt and part of rear seat.
(See Fig. 13)
Figure 12
Figure 12
Figure 13
Figure 13

C.T.M. HS-730 Specifications

General

Brand	C.T.M.
Model	HS-730
Category	Scooter
Language	English
