REV 46578-20140521 22
46578 ENGLISH
Parts List
# Part Number Description Qty
1
26.601.94 Engine 1
2
122.190005.00 Rubber, Fore- Cover, B 1
3
122.190005.01 Rubber, Fore- Cover, A 1
4
123.191100.19 Rotor Assembly, A, 120MM 1
5
2.08.022 Flange Bolt M8×242 1
6
1.96.08 Washer Ø8 1
7
1.7244.08 Lock Washer Ø8 1
8
123.191200.19
Stator Assembly, A,
120MM, No DC
1
9
123.191002.01 Stator Cover 1
10
122.190002.00 End Housing 1
11
2.08.065 Flange Bolt M6×168 4
12
1.97.1.06 Washer Ø6 4
13
1.93.06 Lock Washer Ø6 8
14
122.190300.00 Carbon Brush Assembly 1
15
122.190004.01 Pinch, Carbon Brush 1
16
1.93.05 Lock Washer Ø5 3
17
1.5783.0516 Bolt M5×16 3
18
1.97.1.05 Washer Ø5 2
19
122.190200.05 AVR, Remote Start 1
20
1.16674.0516 Flange Bolt M5×16 2
21
122.190003.00.94 Generator End Cover, Green 1
22
1.16674.0512.2 Flange Bolt M5×12 3
23
122.190400.00 Terminal Block 1
24
122.190018.00 Bracket I, Muffler 1
25
1.16674.0820 Flange Bolt M8×20 3
26
122.190018.01 Bracket II, Muffler 1
27
1.5789.0612 Flange Bolt M6×12 13
28
1.9074.4 0514
Screw/Washer Assembly
M5×14
2
29
46.101503.08 Plate, Spark Arrester 1
30
46.101300.08 Spark Arrester Assembly 1
31
26.101000.00 Muffler Assembly 1
32
23.102000.03.2 Muffler Cover 1
33
1.6175.08 Nut M8 2
34
1.93.08 Lock Washer Ø8 2
35
1.848.08 Washer Ø8 2
36
26.100001.00 Gasket, Exhaust 1
37
23.090006.22 Holder, Air Cleaner 1
38
1.5789.0608 Flange Bolt M6×8 1
39
23.070011.04 Pipe, Fuel (6.1 in.) 1
40
2.06.007 Clamp (Ø8×b6) 2
41
122.070400.05 Fuel Cock 1
42
122.071000.05.94 Fuel Tank, Green 1
43
122.070015.01 Mount Vibration, Fuel Tank 4
44
2.03.004 Washer Ø24×Ø6.5×1.5 4
45
1.5789.0620.2 Flange Bolt M6×20 4
46
23.070301.00 Fuel Filter 1
47
24.070100.00 Fuel Tank Cap 1
48
24.070014.01 Pipe, Reversal Valve 1
49
2.06.006 Clamp (Ø7×Ø1) 3
50
24.070800.00 Reversal Valve 1
51
1.819.0510 Screw M5×10 2
52
122.072000.00 Fuel Meter Assembly 1
53
152.200702.00 Cover, Handle 1
54
122.200700.03.2 Handle 1
55
1.6177.1.08 Flange Lock Nut M8 14
56
1.5789.0845 Flange Bolt M8×45 2
# Part Number Description Qty
57
122.070700.00 Carbon Canister (320cc) 1
58
122.070013.00 Pipe, Air Cleaner 1
59
6.2.246.318.2 Frame 1
60
2.05.001 Clamp (Ø8×6.5) 2
61
122.201200.05 Motor Mount, II 2
62
122.201200.04 Motor Mount, I 2
63
1.6182.10 Lock Nut M10 2
64
122.201701.05.2 8 in. Wheel, Black 2
65
122.200016.01 Bushing (Ø16×Ø10.5×59) 2
66
1.96.10 Washer Ø10 2
67
1.5782.10105 Bolt M10 ×105 2
68
122.200904.00 Strap, Battery 1
69
9.1000.090 Battery 12V9AH 1
70
152.200013.01 Jacket, Wire 1
71
5.1900.010 Red Wire, Battery, 190mm 1
72
122.200013.01 Jacket, Battery 2
73
5.1900.011
Black Wire, Battery,
190mm
1
74
1.5789.0816 Flange Bolt M8×16 2
75
152.200002.00.2 Support Leg, 60MM 1
76
152.201400.00 Rubber, Support 2
77
1.5789.0825 Flange Bolt M8×25 2
78
5.1900.026 Grounding Line, 150mm 1
79
1.6177.1.06 Flange Lock Nut M6 2
80
1.862.06 Lock Washer Ø6 2
81
122.210003.00 Grommet 2
82
1.9074.1.0538.2
Screw/Washer Assembly
M5×38
5
83
122.210002.20 Control Box 1
84
5.1460.003 Indicator Light 1
85
5.1040.004 Remote Program Button 1
86
5.1830.000 Remote Control 1
87
1.823.0514 Screw M5×14 4
88
5.1820.000 Charger 1
89
5.1280.003 Fuse, 10A 1
90
122.159.006.2 Control Panel 1
91
5.1430.001 Intelligauge 1
92
5.1000.001.3 Ignition Switch, Red 1
93
5.1000.000.3 Battery Switch, Red 1
94
1.5783.0622.3 Bolt M6×22, Green 1
95
1.6175.06.3 Nut M6, Green 2
96
1.97.1.06.3 Washer Ø6, Green 2
97
1.93.06.3 Lock Washer Ø6, Green 2
98
5.1120.008 Receptacle L5-30R 1
99
1.9074.4.0414.1
Screw/Washer Assembly
M4×14, Black
6
100
1.6177.1.04.1 Flange Lock Nut M4, Black 6
101
5.1120.034 Receptacle TT-30R 1
102
5.1120.010 Receptacle 5-20R, Duplex 1
103
5.1210.925
AC 25A Breaker, Push
Button, CSA
1
104
5.1210.920
AC 20A Breaker, Push
Button, CSA
1
105
5.1810.001 Over Voltage Protector 1
106
122.210002.14 Control Box 1
107
122.210003.01 Plug, Control Box 1
108
5.1330.001 Sheath, Wire 1
109
122.210003.03 Plug, End Cover 1
110
9.2600.000 Remote Control 1
