Cabela's 46578 - Engine Parts List

REV 46578-20140521 24
46578 ENGLISH
# Part Number Description Qty
1
1.5789.0608 Flange Bolt M6×8 6
2
22.061100.00.2 Recoil Starter Cover, Black 1
3
21.061005.00 Recoil Starter Spring 1
4
2.10.003 Rope (Ø5×1550) 1
5
21.061001.01 Recoil Starter Reel 1
6
45.060003.00 Spring, Ratchet 2
7
45.060002.00 Starter Ratchet (Iron) 2
8
45.060009.00 Spring, Ratchet Guide 1
9
45.060007.00 Ratchet Guide 1
10
45.060008.00 Screw, Ratchet Guide 1
11
24.040004.00 Guide Plate, Push Rod 1
12
1.5789.0612 Flange Bolt M6×12 8
13
24.080100.00.94 Fan Cover, Green 1
14
2.05.010 Clamp (Ø4×6.5) 2
15
21.061300.00 Recoil Handle 1
16
23.125200.01
Relay, Starter (Remote
Control)
1
17
22.061000.00 Recoil Assembly 1
18
24.091000.21 Air Cleaner Assembly 1
19
1.5789.0629 Flange Bolt M6×29 1
20
2.03.016
Washer, Drain Bolt
(Ø10×Ø16×1.5)
2
21
2.02.006 Nut M14×1.5 1
22
21.060001.01 Pulley, Starter 1
23
23.080001.00 Cooling Fan 1
24
24.120100.07 Flywheel, Electric Start 1
25
2.11.001 Oil Seal (Ø25×Ø41.3×6) 2
26
2.03.020.1
Washer (Ø6.2×Ø15×0.5),
Black
2
27
21.110100.00 Gear, Governor 1
28
1.93.05 Lock Washer Ø5 2
29
21.110013.00 Shaft, Governor Gear 1
30
21.110011.00 Clip, Governor Gear 1
31
1.16674.0516 Flange Bolt M5×16 2
32
21.110012.01
Bushing, Govornor Gear
(Iron)
1
33
45.121000.00 Coil, Charging 1
34
23.030006.00 Plate, Coil 1
35
23.080600.02 Air Guide, Right Side 1
36
45.030032.00 Sheath, Wire 1
37
26.030100.00 Crankcase 1
38
21.127000.02 Oil Level Sensor 1
39
23.125100.00 Starter Motor Assembly 1
40
23.050200.00 Connecting Rod 1
41
25.050100.11 Crankshaft 1
42
1.276.6205 Bearing 6205 2
43
24.030008.00 Gasket, Crankcase Cover 1
44
22.031000.00 Oil Dipstick Assembly 1
45
24.091100.21 Base, Air Cleaner 1
46
23.030007.01 Cover, Crankcase 1
47
1.5789.0832.0.8 Flange Bolt M8×32 6
48
2.04.005 Dowel Pin (Ø8×10) 2
49
23.110006.00 Rod, Governor 1
50
21.110003.00 Arm, Governor 1
51
1. 6177. 0 6 Flange Nut M6 3
52
21.110001.00 Shaft, Governor Arm 1
53
22.123000.02 Ignition Coil (Shield) 1
54
1.5789.0625 Flange Bolt M6×25 5
55
23.110005.01 Spring, Throttle Return 1
56
23.110007.00 Spring, Governor 1
57
2.08.040 Bolt, Governor Arm (M6×21) 1
58
21.110008.00 Pin, Shaft 1
59
23.1110 00.20 Control Assembly 1
# Part Number Description Qty
60
25.040013.00 Lifter, Valve 2
61
2.04.001 Dowel Pin (Ø9×14) 2
62
26.041000.00 Camshaft 1
63
2.14.012 Woodruff Key (4×7.5×19) 1
64
2.08.037 Bolt, Drain (M10×1.25×25) 1
65
26.050005.00 Piston 1
66
23.050003.00 Pin, Piston 1
67
2.09.001 Circlip (Ø18×Ø1) 2
68
26.050303.00 Ring, Oil 1
69
26.050302.00 Ring, Second Piston 1
70
26.050301.00 Ring, First Piston 1
71
26.030009.00 Gasket, Cylinder Head 1
72
2.04.003 Dowel Pin (Ø10×14) 2
73
23.040002.00 Valve, Intake 1
74
23.040006.00 Valve, Exhaust 1
75
26.080400.00 Air Guide, Lower 1
76
2.15.002(F6RTC) Spark Plug (F6RTC) 1
77
1.5789.0855 Flange Bolt M8×55 4
78
23.040017.00 Oil Seal, Valve 2
79
21.040003.00 Spring, Valve 2
80
21.040007.00
Retainer, Exhaust Valve
Spring
1
81
21.040001.00 Retainer, Intake Valve Spring 1
82
21.040008.00 Rotator, Exhaust Valve 1
83
24.040202.00 Shaft, Rocker Arm 1
84
22.040009.00 Rocker Arm, Intake Valve 2
85
22.040012.00 Screw, Valve Adjustment 2
86
21.040021.00 Nut, Lock (M6×0.5) 2
87
1.97.1.06 Washer Ø6 2
88
1.6177.1.06 Flange Lock Nut M6 2
89
26 .131017. 2 0 Standard Main Jet 1
26.131017.20.01 Altitude Main Jet /
90
24.040201.00 Retainer, Rocker Arm 1
91
23.040010.00 Bolt, Rocker Arm 2
92
23.040005.00 Push Rod 2
93
21.020002.01 Gasket, Cylinder Head Cover 1
94
24.021000.00 Cylinder Head Cover 1
95
23.020001.02 Breather Tube 1
96
1.5789.0615 Flange Bolt M6×15 4
97
2.01.010 Stud Bolt M8×35 2
98
2.03.021.1
Washer (Ø6.4×Ø13×1),
Black
1
99
24.091200.20 Cover, Air Cleaner 1
100
23.091003.21 Element, Air Cleaner 1
101
23.091001.21 Separator, Air Cleaner 1
102
23.091002.21 Seal, Air Cleaner 1
103
26.010100.00 Cylinder Head 1
104
2.01.003 Stud Bolt M6×90 2
105
24.130002.00 Gasket, Insulator 1
106
23.130001.00 Insulator, Carburetor 1
107
22.130003.00 Gasket, Carburetor 1
108
26.131000.24 Carburetor 1
109
81.130010.00 Spring, Connecter 1
110
26.130015.24 Connecter, Choke Valve Axis 1
111
24.130004.20 Gasket, Air Cleaner 2
112
26.130005.24 Support, Stepper Motor 1
113
45.132200.01 Stepper Motor 1
114
1.823.0408 Screw M4×8 2
115
81.132001.00 Cover, Stepper Motor 1
116
45.030200.00 Support 1
117
2.06.013 Clamp (Ø13.5×b10) 1
118
24.032000.00 Oil Guide Assembly 1
