2018 CONTROL SYSTEM USER MANUAL
9
IMPORTANT INFORMATION
1X FIXED/CHAOS + TRIMLITE
REFERENCE GUIDE
1) Rear Steering Lines
2) Color Coded PU Line Sleeve
3) EVA Floating Bar Ends
4) Line Winders
5) Quickloop Harness Loop
6) Removable Security Pin
7) Bypass Leash Connector
8) Quick Release (QRS)
9) Depower Mainline
10) Trim Lite Handle
11) Trim Lite Cleat
12) Security Line
13) Trim Line Line
14) Trim Lite Power Bracket
15) Front Control Lines
16) Bypass Leash
17) Bypass Leash Quick Release
